How to Check a Washing Machine Motor Capacitor How to Check a Washing Machine Motor Capacitor

What You'll Need
Flathead screwdriver
Needle-nose pliers
Jumper wires with alligator clips on both ends
Multimeter

Where should you look first when your washing machine stops working? While there are numerous parts that could be damaged in your machine, one of the most commons issues is a damaged capacitor. Before replacing your entire motor, you should check this part for problems.

Step 1 – Getting Ready

Warning: Unplug your washing machine before performing any of these steps. Use your machine's insulated handles it's equipped with to avoid electric shock.

When you're ready to begin and you’ve unplugged your machine, remove the rear panel to reach the washer motor. Find the start capacitor, which is the larger of the two capacitors, and remove the metal cover.

Charting Your Wires

Before you change anything, make a chart or take a photo to remember how the motor wires are connected to the capacitor terminals, so you can replace them properly when you’re finished.

Step 2 – Removing Wires

Next, remove the wires from the terminals, using your needle-nose pliers.

Step 3 – Discharging the Run Capacitor

Discharge the run capacitor by placing one alligator clip from your jumper wire to the housing of the capacitor, and place the other on the metal shaft of your screwdriver.

Avoiding Electrical Shock

Then, put the blade of the screwdriver to one of the terminals and the shaft of the screwdriver to the other terminal. This will cause the capacitor to short out, so you don't have to worry about getting shocked from its stored charge.

Step 4 – Setting up the Multimeter

Change your multimeter to the ohm scale. Then, touch the two lead points to one another and switch the adjusting wheel until the needle reaches zero, pointing upward.

Step 5 – Checking the Capacitor

Touch the leads to the capacitor terminals. The black lead goes on right, and the red lead goes on left. This should make the needle of the multimeter jump from zero to the right before going back to zero.

Finally, reverse the leads. This will make the needle move even farther from zero before going back. If the needle doesn't move, this means that your capacitor is not working, and it should be replaced.
